Colors: Solid or white + flecks red, green, blue, black, yellow.
Other colors on demand.
Diameters (mm / inches): 5 to 16 mm / 3/16’’ to 5/8’’
Diameter | Weight | Breaking Load | |||||
mm | inches | ktex | Kg/100m | lbs/100ft | kgf | lbf | kN |
5 | 3/16 | 18,7 | 1,9 | 1,3 | 738 | 1 627 | 7,2 |
6 | 1/4 | 25,6 | 2,6 | 1,7 | 1135 | 2 502 | 11,1 |
8 | 5/16 | 45,5 | 4,6 | 3,1 | 1 750 | 3 858 | 17,2 |
10 | 13/16 | 75,5 | 7,6 | 5,1 | 2 650 | 5 842 | 26,0 |
12 | 1/2 | 100,5 | 10,1 | 6,8 | 3 700 | 3 670 | 36,3 |
14 | 9/16 | 137,5 | 13,8 | 9,2 | 4 300 | 9 480 | 42,2 |
16 | 5/8 | 183,5 | 18,4 | 12,3 | 6 100 | 13 448 | 59,8 |
Elongation at 10% BL | 1,30% | ||||||
Elongation at 20% BL | 2,80% | ||||||
Elongation at 30% BL | 3,80% | ||||||
Elongation at 40% BL | 5,00% | ||||||
Elongation at 50% BL | 5,80% | ||||||
* In accordance with the ISO 10547 2017 ** More diameters on demand |
