Colors: Mix white; Red, Green, Royal Blue, Black, Grey, Yellow and Orange.
Other colors by demand.
Diameters (mm inches): 6 to 10 mm / 1/4’’ to 13"/16’’
Diameter | Weight | Breaking Load | |||||
mm | inches | ktex | Kg/100m | lbs/100ft | kgf | lbf | kN |
6 | 1/4 | 27,6 | 2,76 | 1,85 | 1 524 | 3 360 | 14,9 |
7 | 9/16 | 33,3 | 3,33 | 2,24 | 1 767 | 3 896 | 17,3 |
8 | 5/16 | 47,3 | 4,73 | 3,18 | 2 564 | 5 653 | 25,1 |
9 | 3/8 | 54,3 | 5,43 | 3,65 | 2 730 | 6 019 | 26,8 |
10 | 13/16 | 67,8 | 6,78 | 4,56 | 4 316 | 9 515 | 42,3 |
Elongation at 10% of BL | 0,50% | ||||||
Elongation at 20% of BL | 0,80% | ||||||
Elongation at 30% of BL | 1,00% | ||||||
Elongation at 40% of BL | 1,20% | ||||||
Elongation at 50% of BL | 1,50% |
* In accordance with the ISO 10325 2018
